Roller Welder

Roller Welder

The single-rib brake shoe seam welding machine adopts intermediate frequency welding technology. The intermediate frequency transformer has the advantages of small size, output rectification, beautiful appearance, convenient maintenance and installation, etc. Since the welding power is direct current, the loss in the heating process is small, so as to achieve the effect of saving electricity ( Usually 30% less than ordinary power frequency). The pressurized welding cylinder of the equipment adopts the brand wear-resistant sealing ring, and the double-layer stroke adjustable structure increases the welding stability and shortens the adjustment time for changing the product model.

Different Types of Roller Welder From XIHE

01
Medium Frequency Welder
The medium frequency welding machine has small size, output rectification, beautiful appearance and convenient maintenance, which saves 30% compared with power frequency welding.

Equipment Features of Roller Welder

The equipment adopts three-phase power input with high working frequency. , The transformer loss is small, and the energy saving effect is remarkable. Preheating current, welding current and tempering current can be set, which effectively solves the problem of spatter during welding and work quenching after welding. The three discharge pulses can be set individually and used individually or in any combination. For 1.5mm thick panels and 4-5 solder joints, about 6,000 products can be produced in an average of 10 hours (data provided by cooperative customers).

Equipment Features of Roller Welder

Advantages of Roll Welder

1

The panel rack adopts a hand-crank structure, which greatly shortens the adjustment time. The panel claws are alloyed by vacuum quenching, and the panel pushing mechanism adopts SC-type cylinders. The pushing distance and position can be adjusted arbitrarily to enhance the usable range.

2

The conductive box adopts end-face friction type conduction, and is also equipped with a manual oiling system to improve the maintenance cycle of the point friction parts. The mold clamping adopts a hydraulic clamping system, which can improve the clamping degree and ensure that the ribs will not be smashed during the welding process. Board burns.

3

Three-phase power input, high operating frequency, small transformer loss, and significant energy-saving effect. The preheating current, welding current and tempering current can be set, which effectively solves the problem of spatter during welding and work quenching after welding. The three discharge pulses can be used individually or in any combination.

To Know More About Welding Machine Please Contact Us!
NINGBO XIHE AUTOMATION EQUIPMENT CO.,LTD.
Tel:
+86-0574-88328237
address:
No. 28 Jinteng Road, Wuxiang, Yinzhou District, Ningbo
